LED Video Walls

Pricing depends on configuration, screen size, and pixel pitch. As a general guide:

• Small-format indoor displays (e.g. 2m × 1m feature wall): from $15,000

• Mid-range indoor displays (e.g. 2.5m × 1.5m): from $30,000

• Outdoor displays: from $28,000

• Large-format and custom installs: from $80,000+

Prices include panels, controller, mounting hardware, and standard installation. Structural work, content setup, and CMS licensing are additional.

Contact our Perth team for a free site visit and quote.

A complete LED video wall system requires four core components:

• LED panels: the modular display tiles

• Structural frame and mounting system: holds panels flat, level, and secure

• Video wall processor/controller: receives content sources and distributes the image across all panels

• Content source and management software: a media player, PC, or CMS that feeds video, images, or live data to the display

Permanent commercial installs also require professional cabling, power distribution, and in some cases a dedicated network connection for remote content management.

A video wall is a large-format display system for high-impact visual communications. Common applications include:

• Brand and marketing: products, promotions, and campaign content in retail environments

• Customer engagement: immersive in-store or venue experiences

• Corporate communications: live data, KPIs, wayfinding, and messaging in lobbies and boardrooms

• Collaboration: multi-source content on a shared large-format canvas

• Events and entertainment: high-impact visuals at concerts, conferences, and trade shows

• Control rooms: unified monitoring of live feeds, data streams, and security systems

LED video walls offer several advantages over static and printed signage:

• Visual impact: high brightness output performs in well-lit retail and outdoor environments where printed signage cannot

• Dynamic content: update messaging instantly, schedule campaigns remotely, and react to events in real time

• Operational lifespan: rated for 24/7 commercial operation, with a lifespan exceeding 100,000 hours

• Scalability: modular panels can be configured to any size or shape and expanded as requirements change

• Engagement: digital displays consistently outperform printed alternatives on customer engagement and recall

An LED wall is a type of video wall. Video wall is the broad term for any large-format display made up of multiple screens or panels working together as one image. Video walls can use:

• LED panels (direct-view LED)

• LCD panels (commercial screens tiled together)

• Rear-projection cubes (older technology, rarely specified today)

An LED wall uses direct-view LED modules with no bezels, no visible seams, and the ability to be built to any size. LED walls deliver superior brightness and contrast compared to LCD alternatives.

Yes, but with significant limitations. Consumer TVs can be arranged in a grid with a video wall controller to display a split image across multiple screens. For professional environments, the limitations are:

• Bezels: even thin-bezel consumer TVs leave visible seams between panels

• Brightness: consumer TVs are not rated for sustained high-brightness output in well-lit commercial spaces

• Reliability: consumer panels are not rated for 16/7 or 24/7 operation

• Colour matching: TVs from the same model line can vary in colour temperature and brightness over time, producing an inconsistent display

• Warranty: consumer warranties do not cover commercial use

For anything beyond a home or low-traffic temporary setup, commercial-grade LED panels are the appropriate solution.

Direct-view LED: seamless, high brightness, configurable to any size or shape. Best for large-format commercial installs, events, and outdoor. Higher upfront cost.

LCD video wall: high resolution at close viewing distances, lower entry cost. Thin but visible bezels between panels. Best for control rooms and boardrooms.

Rear-projection cubes: wide viewing angle, but bulky, high maintenance, and largely obsolete. Found mainly in legacy control room installs.

For permanent commercial installations, yes. LED video walls outperform projectors on:

• Brightness: LED walls produce thousands of nits and remain vivid in any lighting condition. Projector output degrades over time and washes out in bright rooms.

• Maintenance: projector lamps require regular replacement. LED panels exceed 100,000 hours with no consumable parts.

• Image quality: direct-view LED produces richer blacks and higher contrast ratios (up to 10,000:1 vs 1,000-3,000:1 for projectors) with more accurate colour.

• Installation: LED walls mount directly to the surface with no throw distance constraints. Projectors require room depth, ceiling height, and clear sightlines.

• Configuration: LED walls can be built to any size or shape. Projectors are constrained by throw ratio and screen geometry.

Projectors retain a cost advantage for very large temporary installations. For permanent commercial use, total cost of ownership typically favours LED.
